Vibrating Screen

Feed Size : 0.29m2

Capacity : 12/h

Application Fields : 在建材石料里广泛使用。 适用领域为选煤、选矿、电力和化工

Introduction : Vibrating screen is very difficult to screen suitable for wet fine grained material dry sieving vibrating screen points of mechanical equipment.

Offical Email : [email protected]
Skype : dongfanggroup

       This Vibrating Screen is used for powder material classification, with good effect, 60-200 mesh. Power supply 0.75-3KW, output:500-1500KG/hour.

       Main technical parameters of Vibrating Screen:

Name Model Working area m2 Sieve layers Max. feeding size mm Capacity t/h

Sieve pore size mm

Vibrating frequency Power KW

Individualized vibrating  screen

400*800 0.29 1 50 12 1-25 1500 1.1
400*800 0.29 2 50 12 1-15 1500 0.5
800*1600 1.2 1 100 20-25 3-40 1430 2.2
900*1800 1.52 1 60 20-25 1-25 1000 2.2
900*1800 1.52 2 60 20-25 1-25 1000 2.2
1250*2500 3.15 1 100 150 6-40 850 5.5
1250*2500 3.15 2 150 150 6-40 1200 5.5
